S7-C
- 10 A @ 250 V
- 16 A @ 250 V (for 1-pole use)
- screw terminal
- 16 A @ 250 V (for 1-pole use)
- screw terminal
ELDAS®:
8.42804E+12
| - All terminals / DIN rail | 2.5 kV rms / 1 min |
|---|---|
| - Multi wire (un-crimped) | 2.5 mm2 / AWG 14, 2 x 1 mm2 / AWG 18 |
| - Single wire | 4 mm2 / AWG 12, 2 x 1.5 mm2 / AWG 16 |
| - Terminal / terminal | 2.5 kV rms / 1 min |
| Conductor cross section | |
| Housing material | PA / PC |
| Mounting | TH35 (EN 60715) or back panel mounting |
| Nominal screw torque | 0.7 Nm |
| Operation temperature | -40 … 60 °C (50 °C for 16 A) |
| Rated load | 10 A, 16 A for 1 pole / 250 V |
| Screw Dimension | M3 Pozi slot |
| Storage temperature (no ice) | -40 … 80 °C |
| Weight | 37 g |
| Approvals | UKCA,CE,cURus,EAC,LR,CSA |
|---|---|
| Standards | EN 60664-1 |
Approvals
3D-models "S7-C"
